Charging Box
● LCD screen.
● Easy installation.
● High compatibility.
● Waterproof grade：IP554
● Over-voltage protection/lightning protection.
● Real-time monitor on charging temperature.
● Error correction & reboot system.
EV Connector
● Excellent protection performance.
● Keep EV connector working even if use in a rainy day.
● Good conductivity.
TPU/TPE Cable
● Durable and anticorrosion.
● Easy to bend, long service life.
● High resistance to cold, high temperature
Before running, please carefully check and ensure the following:
·The installation position of the charging station is convenient for operation and maintenance;
·Connect the charging station and accessories correctly and install them firmly;
·Reasonable selection and installation of AC incoming leakage protection circuit breakers;
·The relevant accessories of the charging station are complete, and the charging gun is in a suspended state.
Electrical Specification
| Input voltage/Output voltage | 380V±20% |
| Input frequency | 50Hz |
| Max. output power | 30~180kW |
| Max. output current | 5A~190A |
| Charging interface type | Type 2(IEC 62196-2), Type 1(SAE J1772) |
Working Environment
| Protection Degree | IP54 |
| Environment Temperature | -20℃ ~ +50℃ |
| Relative Humidity | 5%-95% non-condensing |
| Maximum altitude | <2000m |
| Cooling method | Natural cooling |
| Standby Power Consumption | <3W |
Customer Service
● We can provide customers with professional product advice and purchase options.
● All emails will be responded within 12 hours during working days.
● All customers will get one-on-one service.
Customized Service
● We provide flexible customized services with our abundant experiences in kinds of OEM and ODM projects.
● OEM includes color, length, logo, packaging, etc.
● ODM includes product appearance design, function setting, new product development, etc.
● MOQ is depend on different customized requests.
After-sale Service
● The warranty of all our products is one year.
● The specific after-sale plan will be free for replacement or charging a certain maintenance cost according to the specific situations.
